CE, ISO9001: 2000
Fabric Cutting Machine Industrial Fabric Cutting M
Cutting Thickness(After Vacuum Suction)
Max50/70/90mm(According to The Cloth)
Straight Knife up-Down
Automatic Cutting System Copyright
The Standard Package Is Plywood Packages(20′ Fr)
Cutter markets suitable for widely industly ,for instance :Leisure fashional suits,children's garments,suits,
Knitting casual/leisure suits,underware,swimsuit,corsage,seat cushion,massage chair,yacht/houseboat seat,shoes,cat,cold protective clothing,golf bag,handbag,home textiles,cow-bag,sleeping bag,tent, apparel,
Automotive, and furniture and soft fabric as well as other industries.
Video of fabric cutting machine link as below:
|TMCC- 2025 ,Garment mesh fabric material ,190 Layers,after-absorption 6cm||https://youtu.be/NppLdAcVykw|
|TMCC- 2025 ,black knit material,150 Layers(Max 190 layers),after-absorption 8.5cm(Max 9cm)||https://youtu.be/anKgT0YZrhQ|
|3,Mainly for baby's cloth material ---Cotton jersey,cutting 60 layers ,after-absorption reach to 7CM||https://youtu.be/3O1EqKtKXB4|
|Cutting thickness(after vacuum suction)||Max50/70/90mm(according to the cloth)|
|Cutting style||Straight knife up-down|
|Softerware||Automatic cutting system copyright|
|Custermization about length, width,s trength is acceptable|
Important Standards Size:
After vac-sorb Cutting thickness:5cm 7cm 9cm
C Model effective cutting width(mm):1600 1700 2000 2200 2500
(multil layer effective cutting length(mm):2000 2500 3000 3300
After vac-sorb Cutting thickness:3mm ( according to the material and decided it)
S Model effective cutting width(mm):900mm
(singlelayer) effective cutting length(mm):9000mm
* Computer design, automatic typesetting, save original materials.
* Computer controlled and automatic cutting, save the human resource, mass production.
* Support many kinds of formats, direct open general dress design format, typesetting software.
* The unique algorithm and motion control technology, realized seamless between straight line and arc.
* High cutting accuracy, self-design of automatic sharpen cutter, high quality of cutter makes life longer.
* No need print out, save the typesetting, with high repeated utilization, plate marking management is convenient.
* Easy to change the spare part, and lower cost;
* Nice automation, easy to operate.
Eight Main Advantages
1>.With Europe and the United States the single knife design concept system to replace the original double disrotatory structure, makes the blade sharpness doubled, meanwhile ,takes idle running sharpen knife ,save the time of sharpening process, in order to improve cutting efficiency.
2>. Control system is the most advantage, whole software control system is belong to tanning's copyright .we have great advantages for future updating and maintenance.
3>.uniform absorption:vacuumchamber takes uniform absorption working way, avoid general adsorption (vacuum chamber flow direction from this side to other side ) makes deformation of the material ,guarantee the cutting accuracy .
4>.Air Pump use motor and fun together, decrease energyconsumption, enlarge suction power, noise lower than split pump.
5>. The nose framework takes Steel material,Chrome plated on the surface, compared with Traditional aluminum material, double increased nose intensity and Stability and service life.
6>.ata compatibility,tianming cloth cutting machine support PLT format which is widely used all over the world ,that is to say all CAD software can output this format .
7>. Except control system ,cutting accuracy and power is depends on servo motor .We use Panasonic servo motor and diver to guarantee the machine accuracy and stable .
8>.Encryption support beams:double increase encryption support beams ,improve machine stability and longer life .
Welcome to contact me for moreinformation!
When sending inquiry, please let me know:
1,Which material do you need to cut or engrave ?
2,What is the size and thickness?
3,What is your business industry?
3,Which country will the machine be shipped to ?
4,May I have your name, company name, email and telephone?
With above confirmation, we would like to quote you the most suitable model's price, videos, sample photos and more specifications ASAP.
