Company IntroductionQingdao Haijia Machinery Co., Ltd. was established in 1995, since its establishment has been focused on the development of manufacturing water jet loom, is currently set research and development, manufacturing, sales and service as one of professional manufacturer of the largest water jet loom, is the participation of China water jet loom industry standards makers. Water jet loom sales for , the industry's firs 13 consecutive years, is China's textile machinery governing unit.
Haijia machine is China No. 1 brand in the textile field.
More than 70000 sets machine are running successfully.
21 years experience in manufacturing textiles.
Annual capacity of 6000 sets.
20% of the total global market, global one!
|Haijia machinery HJA-N main technical parameters|
Staple:100-5S/1 (Inch cotton counts)
|50~ 900D (55.6~1000dtex)|
|Fabric gram weight: 500(denim)-30(gauze)g/Square meter|
|Weft insertion rate||1600~2200M/min|
|Weft selection||Single nozzle,double,quadruple,sextuple nozzle free weft choose|
|power||The location of parking is controlled directly by electromagnetic|
|super stared motor:(cam shedding);(Dobby shedding);(jacquard shedding)|
|button switch operated by both hands,double sides can be|
|Weft insertion||adopt the main and auxiliary nozzles simultaneously||Extension nozzle|
|use profile reed||ABS weft brake|
|auxiliary main nozzle|
|crank connection rod shedding: heddle frame: 4pieces or six pieces.|
|active cam shedding: utmost 10 pieces.|
|dobby shedding: utmost 16 pieces|
|electric control continuous positive let off|
|single warp beam.||Double warp beams|
|(0~8mm)active loose warp device|
|∮800mm warp side pan diameter||∮914∮1000mm|
|electronic take up||mechanical take up|
|Range of weft density:18-204threads per inch.|
|∮600mm(cam,dobby,jacquard shedding)∮520mm(crank shedding)|
|beating-up||crank type more sley beating-up system|
|4 linkage beating(narrow) 6 linkage beating(wide)|
|weft measuring||vibrating weft feeder||(FDP)electric drum weft|
Floor type four yarn cones(2nozzle),floor type 8 yarn cones.
|fabric edge||planetary gear type leno-selvage device||medium cutters|
|Yarn end processing||left side winding 3 drum types|
|lubrication||main transmission part is oil-bath type,one-time oil filling by hands|| |
Auto one time-oil filling
|Parking device||Weft:photoelectric weft feeder,double probe|
|Warp:electrical contact 6 columns dropper|
|Other:self-stop when yarn is broken|
|Parking reason indication:message showing on man-machine interface,|
parking indication with four color lamps in multi-function
|Control:multi-functional computer control system featuring parameter|
setting/control/monitor/self diagnosis/artificial intelligence interface.
|Broken weft finder device:automatically find shed|
|Slowly motion available through AC Driver(forward and reverse)|
|other:monitor output terminal|
|injection automatic control|
