Wool Cashmere Acrylic Yarn Fiber Spinning Line Carding Machine PriceThis TD288 Combined machine line including the Feeder, the Opening&Rectiliner Combing Machine, the Cashmere Carding machine, which is applicable to carding of materials like cashmere, camel\'s hair, yak wool, etc. The washed cashmere will be fed uniformly th

Featured Products

Wool Cashmere Acrylic Yarn Fiber Spinning Line Carding Machine Price



This TD288 Combined machine line including the Feeder, the Opening&Rectiliner Combing Machine, the Cashmere Carding machine, which is applicable to carding of materials like cashmere, camel's hair, yak wool, etc. The washed cashmere will be fed uniformly through this machine's automatic feeder after these materials are preliminarily opened by the teaser card after being gradually opened, dehaired and removed of coarse wools and trashes, and then be made into high content of quasi dehaired wool for the next process to make standard dehaired wool. This machine has two main parts: the opening & carding part and the rectilinear combing and coarse-removing part, between which is connected by the flat lattice.
Textile Machinery Blowroom Carding Machine Textile Machine for Spinning Line

Main Technical Data:

MAIN TECHNICAL SPECIFICATIONS AND PARAMETERS
Nominal width1000mm
Opening chest Cylinder dia. 698mm
Pairs of working rollers: 6 pairs
Stationary Flats of rectilinear combing Cylinderfront 1 rear 1
Rectilinear combing Cylinder dia. 380mm
Output8-10kgs/h
Finished cashmere content≥80%
Fiber damage≤5%
Total power 4.47KW  (including feeder)
Overall size 9500 X2036X1520(L*W*H)

Detailed Specification:
Textile Machinery Blowroom Carding Machine Textile Machine for Spinning Line

Advantage:
Reasonable process flow, easy maintenance; adopt central control by an electric box for the whole line; touch screen. Through which all the technical parameters can be adjusted conveniently and promptly.
Textile Machinery Blowroom Carding Machine Textile Machine for Spinning Line

Other Related Model:
MAIN TECHNICAL SPECIFICATIONS AND PARAMETERS
NameFeederOpening&Rectiliner Combing Machine
ApplicationIt's used to store materials in reserve box, to precisely pluck suitable materials within unit time through the inclined spike lattice and to evenly convey materials to the next process.The main function is to open materials and remove coarse wools. After being process by this machine, materials will be opened into parallel and straight filaments, while large amount of dusts, burrs andcoarse wools are removed.
CharacteristicsNot only material blending efficiency. but alsoopening and trash extraction.
The speed of inclined spike lattice is adjusted byan inverter according to technology requirements.
The evener rake (lattice) ensures uniform feedingof materials.
Two groups of opening Cylinders, Six groups of working rollers, four groups of arrayed coarse-removing rollers. The first group of opening Cylinders is of slow opening; the second group of opening, Cylinders is of fine opening, gradual opening and coarse removing without damage to fibers. Four groups of coarse-removing rollers are of different speeds, and can remove coarse wools gradually without hair droppings and with a large amount of coarse wools and trashes removed.
Inverter control, adjust the speed according to diferent materials and output, simple and prompt.
Special carding clothing is fixed.
Working Width970mm/1450mm1020mm/1500mm
Total power 1.1KW  /1.47KW2.8KW  /3.3KW
Overall size (mm)1890X1360X2100(L*W*H)
2200X1840X2100(L*W*H)
4820X1770(2250)X1500(L*W*H)


Textile Machinery Blowroom Carding Machine Textile Machine for Spinning Line

Packing and Shipping:
Textile Machinery Blowroom Carding Machine Textile Machine for Spinning Line

FAQ:
(1) Q: How's the after-sale service?
   A: We offer engineers available to service overseas under merchandiser's supervision and translation.

(2) Q: Are you available for on-the-spot invitation?
   A: We do welcome our new and old friends come here to have a visitation. Besides, we would send you our exposition and relative information to promote a face-to-face meeting if you'd like to.
(3) Q: Is the price offered changeable?
   A: We offer reasonable price for every client, and the price is changeable according to purchasing amount.
(4) Q: How about the quality?
   A:The main subassembly and raw materials are all supplied by large companies. Key parts are research and developed by our own staff. Professional assembly line work and strict quality test system can ensure your high quality requirement.
(5) Q: Are you a manufacturer or Trade Company?

   A: We are a professional manufacturer holding our own International Trade Department, for that we can better understand customer's needs and offer a reasonable price.

Why Choose Our Company?
Textile Machinery Blowroom Carding Machine Textile Machine for Spinning Line
A: History: TONGDA Textile Machinery Group was establish in 1952. Now have more than 65 years old history.
B: Main Products: Tongda Group specializes in design, manufacturing, and marketing of a wide range of Textile machinery, it has seven branch companies, mainly produces ring spinning frame, roving frame, weaving machine(water Jet loom/Air jet loom/rapier Loom),warping machine, quilting machine and nonwoven machine.
C: We provide design for complete line of spinning mill for cotton yarn, polyester yarn, wool yarn, flax/linen yarn, machines including blow room, carding machine, draw frame, roving frame, ring frame, winding machine, open end spinning machine and the air conditioning system and waste collection system for spinning mill.
We also provide workshop layout design and trench design, and air pipe layout design.
D: Product /Quality Guarantee: 1 year warranty for the International standard.
E: After Sale Serivice: We are work online 24 hours. If you have any questions about our machine you can contact us.
F: One-stop Service:
We have R&D department including more than 100 engineers which are improving and enlarging our supply range.

Export Memorabilia:
TONGDA 1988: TONGDA's 500 sets ring spinning machines was exported to Bangladesh.
TONGDA 1993: TONGDA's 385 sets spinning machines was exported to Pakistan.
TONGDA 1995: TONGDA's 229 sets spinning machines was exported to Bangladesh.
TONGDA 2002: Delivery 300 sets spinning machines to India.
TONGDA 2009: TONGDA's 100 sets water jet loom and air jet loom was exported to India.
TONGDA 2010: TONGDA once again exported 300 sets water jet loom and air jet loom to India.
TONGDA 2011: TONGDA exported needle punching nonwoven machine production line to south America and exported more than 500 sets water jet loom, air jet loom, rapier loom to overseas.
TONGDA 2012: TONGDA exported 200 sets spinning machine and 100 sets rapier loom to Tajikistan and once again exported 200 sets ring spinning machines to India.
TONGDA 2013: TONGDA exported 500 sets weaving machines to overseas and 50 sets nonwoven machines, 680 sets spinning machines to overseas including South Asia and Africa.
TONGDA 2015: TONGDA sold more than 1000 sets weaving machines, 100 sets nonwoven machines and 700 sets spinning machines to overseas including Europe, South America, and South-East Asia.

Certification:
TONGDA is an ISO9001, ISO14001, and ISO13485 company. The products are designed to meet the technical standards of 3C and CE. All the products are certified by the Industry Administration Authority. TONGDA will continue to strive to be a stronger leader in the global market of Cotton machinery and Spinning machinery.
